Makale / Article

2. Şekil Hafızalı Polimer Uygulamaları                                  This mechanism is basically applicable for other types
Şekil hafızalı polimerler ve kompozitlerine, akıllı kıyafet             of SMPs containing dual-domain systems. Additional
ve sensör uygulamalarından mandrel (tekrar kullanılabi-                 segments or fillers may be added to enhance perform-
len) üretiminine kadar oldukça geniş çaplı bir uygulama                 ance such as multiple transitions, electrical conductiv-
yelpazesiyle karşılaşmaktayız. (Everhart ve Stahl 2005,                 ity and strength. Overall, the driving force behind the
Everhart ve ark., 2006, Dietsch ve Tong 2007, Snyder ve                 SMPs is the elastic energy stored in the elastic segment
ark., 2010, Hu J 2007, Leng ve Du 2010). Termal ola-                    (Huang et al. 2010a).
rak duyarlı şekil hafızalı polimerlerin büyük bir potansiyel            2. Applications of Shape Memory Polymers
teşkil ettiği örneklerle incelenecektir.                                A wide range applications of SHPs have been encoun-
Görme engelli ya da körler alfabesi olarak bilinen kıs-                 tered from re-usable mandrels to use in intelligent
mi ya da tam olarak görme engeli olan insanların do-                    clothing and sensor applications. (Everhart and Stahl
kunarak okuyup yazmasına yarayan baskılardan meyda-                     2005, Everhart et al., 2006, Dietsch ve Tong 2007, Sny-
na gelmektedir (Şekil 2). Bu alfabe çıkıntı noktaları içe-              der et al., 2010, Hu J 2007, Leng ve Du 2010). Ther-
ren 3*2’lik matristen oluşmaktadır. Bu noktalar genellik-               mally sensitive shape memory polymers will be dis-
le iÄŸne ve levha sistemiyle ya da otomatik olarak plastik               cussed with examples that constitute a huge potential.
veya kâğıt yapraklarına termoset olarak yazılması (çıkarıl-             Visually impaired alphabet (Braille) comes from the
ması zordur) tekniği ile elde edilmektedir.                             prints that are used to read and write people with
Yazısal hataların kolay giderildiği ve tekrar yazılmaya                 partial or complete visual impairment. Braille writing
müsait, yeni nesil görme engelli alfabesine ihtiyaç duyul-              consists of a set of bump dots in a 3*2 matrix. These
maktadır. Görme engellilere yardım etme amacıyla po-                    points are usually obtained by the needle and plate
liüretan şekil hafızalı polimerinden levha geliştirilmiştir             system, or automatically by thermosetting on plastic
(SMP Technologies, Japonya). Şekil 3’te gösterildiği gibi               or paper sheets (difficult to remove) technique.
meydana gelebilecek herhangi noktasal hatalar, nokta
ısıtıcılar yardımıyla düzeltilebilecektir. Sonradan yapıla-                      Şekil 2. Körler alfabesi yazım kuralları (a)
cak düzeltmeler aynı bölgeye yapılabilmektedir. Buna ek                                         ve uygulaması (b).
olarak levhanın tamamı ısıtıldığında tekrar tekrar geri ka-
zanılabilme özelliğine sahiptir. Şekil hafızalı polimerlerin                 Figure 2. Spelling rules (a) and application of
düşük fiyatları sayesinde görme engelli insanlar için uy-                                      Braille alphabet (b).
gun ve ucuz yenilikler uygulanabilmektedir.

  Şekil 3. Şekil hafızalı görme engelli alfabesi (a) yazma işlemi, (b)  A new generation of visually impaired alphabets is
 yazma sonrası görünüm (f) nokta ısıtıcı kullanılarak noktaların tek    needed that can be easily rewritten, making it easier
tek kaldırılması işlemi (Huang WM, in Shape-Memory Polymers and         to fix errors. A sheet of shape memory polyurethane
                                                                        has been developed in order to help the visually im-
         Multifunctional Composites, Taylor & Francis, 2010.).          paired (SMP Technologies, Japan). As shown in Figure
Figure 3. Braille alphabet papers produced from SMPs: writing (a),      2, any point defects may occur will be corrected with
through (b) and erasing dots using a point heater in a one-by-one       the help of the point heaters. Corrections to be made
manner (c-f). (From. Huang. WM., In Shape-Memory Polymers and           later can be made to the same region. In addition, the
                                                                        entire sheet has the ability to be recovered repeatedly
          Multifunctional Composites, Taylor & Francis, 2010)           when the sheet is heated. Affordable and cheap in-
                                                                        novations for visually impaired people can be applied,
                                                                        thanks to the low prices of shape memory polymers.
